Hydro Mount
Hydro Mount DL & VL: Advanced Vibration Isolation Solutions
Hydro Mount DL: Ideal for High-Performance Applications
The Hydro Mount DL is a state-of-the-art hydraulically damped rubber mount designed to overcome the challenges of mounting masses subjected to a wide frequency spectrum. It excels in applications where low-frequency vibrations (5-15 Hz) are a primary concern.
| Name | Height | Length | Width | Thread Size | Hole Centre L | Hole Centre W | Mounting Holes | Shore Hardness | Quantity | |
|---|---|---|---|---|---|---|---|---|---|---|
| 036 18 716-40 | 103.2 | 105 | 91.5 | 16 | 80-82.7 | 65-69.4 | 4 | 40 | ||
| 036 18 716-50 | 103.2 | 105 | 91.5 | 16 | 80-82.7 | 65-69.4 | 4 | 50 | ||
| 036 18 716-60 | 103.2 | 105 | 91.5 | 16 | 80-82.7 | 65-69.4 | 4 | 60 | ||
| 036 18 716-70 | 103.2 | 105 | 91.5 | 16 | 80-82.7 | 65-69.4 | 4 | 70 | ||
| 036 18 707-70 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 70 | ||
| 036 18 706-40 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 40 | ||
| 036 18 706-45 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 45 | ||
| 036 18 706-50 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 50 | ||
| 036 18 706-55 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 55 | ||
| 036 18 707-40 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 40 | ||
| 036 18 706-60 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 60 | ||
| 036 18 707-45 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 45 | ||
| 036 18 706-65 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 65 | ||
| 036 18 707-50 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 50 | ||
| 036 18 707-55 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 55 | ||
| 036 18 707 60 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 60 | ||
| 036 18 707-65 | 119 | 140 | 140 | 16 | 110 | 110 | 4 | 65 |
