BA & Double U Shear
BA & Double U-Shear Mountings: Versatile Vibration Isolation Solutions
BA and Double U-Shear mountings are both well-suited for isolating vibrations from low-speed machinery and equipment, safeguarding delicate and lightweight components from external shocks and vibrations. These mountings employ bonded rubber in shear, which allows for significant deflection, ensuring superior isolation at low frequencies. (The BA 20/2 type is a half-section designed for very light loads.)
| Name | B | Length L | Height H | Hole Centre A | Bolt Size D | T | Max Load Kn | Quantity | |
|---|---|---|---|---|---|---|---|---|---|
| 17-4345-40 | 20 | 90 | 58 | 62 | 8 | 4 | 120 | ||
| 17-4345-60 | 20 | 90 | 58 | 62 | 8 | 4 | 270 | ||
| 17-1482-00 | 51 | 60 | 41 | 3 | |||||
| 17-1482-01 | 51 | 60 | 41 | 3 | |||||
| RB3635 | |||||||||
| 17-4035-40 | 20 | 90 | 50 | 4 | |||||
| 17-4035-60 | 20 | 90 | 50 | 4 | |||||
| 17-4036-40 | 50 | 90 | 50 | 4 | |||||
| 17-4036-60 | 50 | 90 | 50 | 4 | |||||
| 053 18 001-50 | 65 | 87 | 108 | 5 | |||||
| 053 18 001-65 | 65 | 87 | 108 | 5 | |||||
| 053 18 001-75 | 65 | 87 | 108 | 5 | |||||
| 053 18 002-50 | 50 | 81.5 | 78 | 4.5 | |||||
| 053 18 002-65 | 50 | 81.5 | 78 | 4.5 | |||||
| 053 18 003-50 | 25 | 71 | 62 | 4 | |||||
| 053 18 003-65 | 25 | 71 | 62 | 4 | |||||
| 053 18 003-75 | 25 | 71 | 62 | 4 | |||||
| 053 18 002-75 | 50 | 81.5 | 78 | 4.5 | |||||
| 053 18 004-50 | 20 | 61 | 43 | 3 | |||||
| 053 18 004-65 | 20 | 61 | 43 | 3 |
